Polymer Pour Point Depressant

ZX-P4-09 polymer Pour Point Depressant is specifically formulated to improve the flow properties of crude oil in cold temperatures. It effectively reduces viscosity and prevents the formation of wax crystals, enabling smooth oil transport in freezing conditions.

Polymer pour point depressant ZX-P4-09 Beyond polymer pour point depressant has a strong effect in lowering the pour point of specific crude oil by interacting with paraffins in the crude. The product inhibit the formation of large wax crystal networks and can significantly lower the pour point of the crude. This series of products are productive where Beyond's various kinds of fatty alcohols contribute the needed raw materials, so the products can be applied to different types of crude oil.

Polyester polymer

Evaluation method in lab

Add the pour point depressant into it when the target crude oil was heated to formation or gathering pipe network temperature. Constant temperature for one hour after mixing. And then to test the freezing point of pour point variation of crude oil before and after adding PPD. Also it can be cooled to 3-5℃ above the freezing point of crude oil, then to test the viscosity variation of crude oil before and after adding PPD. In general, its dosage will be recommended as 0.01% to 1% but the actual dosage can be freely determined according to the different condition.

Application and Usage

Crude oil loses its fluidity because the wax dissolved in the oil crystallizes and precipitates when the temperature drops. As the oil temperature drops, the solubility of the wax gradually decreases. The wax crystals overlap and connect with each other to form a three-dimensional spatial network structure, and the crude oil loses its fluidity. Pour point depressants do not undergo chemical reactions with crude oil. Instead, they alter the size and shape of wax crystals, preventing them from forming a three-dimensional spatial network structure. However, pour point depressants cannot inhibit the precipitation of wax crystals; they can only change their morphology, weakening their ability to form a three-dimensional spatial network structure, thereby enhancing the fluidity of crude oil.

This product is formulated with high-carbon alcohol compounds, which provide excellent solubility in crude oil and prevent pour point issues. It is effective in temperatures as low as -20°C and works across a wide range of crude oil types, from light to heavy.

Since implementing ZX-P4-09 in our pipeline operations, we've seen a significant improvement in flow, even in sub-zero temperatures, reducing downtime and maintenance costs.

Compared to traditional pour point depressants, ZX-P4-09 offers superior performance in preventing wax formation and reducing crude oil viscosity, even in extreme cold conditions. Its high-carbon alcohol formula ensures longer-lasting effects and greater efficiency in low-temperature environments.

Site application:

1, Can be used for oil production, gathering and transportation of crude oil;

2, Can add an aromatic solvent to dilute PPD, continuous or batch injection in production facilities;

3, Dosage is 0.01% to 1% but the actual dosage can be freely determined according to the different condition.

Packaging

200L steel drum or 1000L IBC or per clients' request.

Storage conditions

1, Polymer pour point depressant ZX-P4-09 PPD should be stored in a cool, dry and ventilated area in tightly closed containers;

2, In above storage, situations, for material in original, unopened, properly stored containers, the shelf life is two years from the production date.

3, Further information, pls consult technician for reference.
